Material: valve body made of SPCC, mounting ring made of galvanized steel.
Finish: RAL9010, RAL9016 or RAL 9003 as per customer request.
The valve body is equipped with a cellular plastic gasket to form an air-tight seal.
The air flow is adjusted by rotating the control disc.
| Item code | ØA(mm) | ØB(mm) | ØC(mm) | D(mm) | H1(mm) | H2(mm) |
| EAV 80 | 115 | 62 | 77 | 79 | 40 | 50 |
| EAV 100 | 138 | 75 | 97 | 99 | 40 | 50 |
| EAV 125 | 164 | 100 | 122 | 124 | 46 | 50 |
| EAV 150 | 202 | 120 | 147 | 149 | 50 | 50 |
| EAV 160 | 208 | 130 | 157 | 159 | 54 | 50 |
| EAV 200 | 248 | 158 | 197 | 199 | 58 | 50 |
| EAV 250 | 305 | 208 | 245 | 249 | 62 | 45 |
